EVO CUT 45 PFC Inverter
c/w Plasma Cutting Torch 6m, Earth Return Lead 3m

Order Code: EP-45

List Price: £1475

Discount available from your local dealer

Key Features

• Rugged, ergonomic design

• Ideal for cutting steel, stainless, copper, cast iron & aluminium

• ClearVision technology

• Adaptable wide voltage range

• HF stabilising technology

• SurePlasma technology for consistent arc ignition performance with different torch lengths

• Mesh cutting, 2T/4T, non HF arc ignition and pilot arc

• Gas check, postflow and time setting

• Cutting torch length setting

• Power factor correction (PFC), generator friendly

• Quick factory reset; auto sleep mode

• ABAP: Active Balancing Air Passage

• Fan on demand

• Key power electronic component protection

• Overcurrent and overheat protection

• TFT screen, compressor & trolley (optional)

Industrial Design Highlights

Lateral Plate

Detachable for easy servicing, reinforced for enhancing the structures impact strength.

Front Grill

A sloped front grill offers a perfect balance between heat dissipation and ingress protection (IP23S).

Overall Look

Rugged, robust and industrial.

Control Panel

Slanted 45° angle for enhanced visibility and viewing comfort.

Streamlined Handle

Elevates overall aesthetics of the power source and provides a comfortable, firm and glove-friendly grip.

Choice of Cutting Modes

Select between 2T/4T latch or mesh cutting.

Auto Sleep Mode

The power source will enter standby mode after being idle for 10 minutes. This will reduce the power consumption to below 15W and reduce energy costs.

Wide Voltage Adaptation

95

265 50/60 Hz

Compatible with input power sources of AC 95-265 volts.

Power Factor Correction (PFC)

Improves overall energy efficiency and allows use with AVR generators.

Overheat & Overcurrent Protection

The overheat warning light indicates that the machine has entered overheat protection and stops the welding output, the machine will re-activate once the unit has cooled down.

The overcurrent warning light indicates that the machine has entered over-current protection and stops the output. The machine can be reset by turning off and then back on.

Quick Factory Reset

Quick reset to the factory programmed settings in the
event of the operator selecting an incorrect setting.

Generator Friendly

The EVO CUT 45 PFC inverter can be used with an AVR (Automatic Voltage Regulator) type power generator.

Recommended size is 5.5 kVA (AC 115V) and 8 kVA (AC 230V).

EVO TFT (PLASMA) Screen

Order Code: TFT-EP-45

EVO Inverter Trolley

Order Code: JIT-01

Optional Accessories

EVO Compressor

Order Code: EP-SC

Mesh

Cutting

SurePlasma

Technology

for non HF Cut

Welding

Engineer

Mode

Wide Voltage

Adaptation

On Demand

Fan

Energy Saving

Environment

Friendly

Input

Power Source

Power Factor

Correction

PFC

SurePlasma

Advanced SurePlasma technology that offers consistent (non HF) plasma arc ignition. The machine automatically calculates the optimum start conditions based on the torch length.

HD digital panel providing crisp and clear reading, visible under direct sunlight.

With 45° slanted angle for improved visibility and a 41% enhanced

viewing area compared to a vertically positioned control panel.

Ideal Solution for Cutting Mesh

For cutting mesh or metal with gaps. Mesh mode eliminates the need for repeated start/start pressing of the torch trigger.

Active Balancing Air Passage

Internal airflow is optimally diverged by a segregation structure.
The divergence of airflow can dissipate heat generated by power electronics in a more balanced manner.
The power source's overall reliability is improved with the internal structure design.
