EVO TIG 200P PFC Inverter
c/w Carry Case, TIG Torch 4m, Regulator, Hose & Lead Set
Order Code: ET-200P
List Price: £975
Discount available from your local dealer
Key Features
• Rugged, ergonomic design
• ClearVision technology
• Full featured DC pulse TIG parameters
• Adaptable wide voltage range
• Dash-Arc
• Smart Lift TIG
• Flexible remote control solutions (optional)
• Power factor correction (PFC), generator friendly
• Quick factory reset; auto sleep mode
• ABAP: Active Balancing Air Passage
• Smart gas for optimised shielding gas consumption
• Fan on demand
• Voltage Reduction Device (VRD)
• Key power electronic component protection
• Overcurrent and overheat protection
• Complete with protective case, torch, leads, regulator
Industrial Design Highlights
Overall Look
Rugged, robust and industrial.
Control Panel
Slanted 45° angle for enhanced visibility and viewing comfort.
Streamlined Handle
Elevates overall aesthetics of the power source and provides a comfortable, firm and glove-friendly grip.
Front Grill
A sloped front grill offers a perfect balance between heat dissipation and ingress protection (IP23S).
Lateral Plate
Detachable for easy servicing, reinforced for enhancing the structures impact strength.
Next generation HD digital panel providing crisp and clear reading, visible under direct sunlight.
With 45° slanted angle for improved visibility and a 41% enhanced
viewing area compared to a vertically positioned control panel.
Dash-Arc
Dash-Arc technology for HF TIG. Delivers 99+ % arc striking success rate, high consistency and high ignition response rate (50-60ms).
Smart Gas
Automatic post flow time adjustment for TIG welding according to actual welding current and time, etc. Reduces shielding gas consumption up to 40% compared to conventional products.
Wide Voltage Adaptation
95
265
Compatible with input power sources of AC 95-265 volts.
Auto Sleep Mode
The power source will enter standby mode after being idle for 10 minutes. This will reduce the power consumption to below 15W and reduce energy costs.
Overheat & Overcurrent Protection
The overheat warning light indicates that the machine has entered overheat protection and stops the welding output, the machine will re-activate once the unit has cooled down.
The overcurrent warning light indicates that the machine has entered over-current protection and stops the output. The machine can be reset by turning off and then back on.
Generator Friendly
The EVO TIG 200P PFC inverter can be used with an AVR (Automatic Voltage Regulator) type power generator.
Recommended size is 5 kVA (AC 115V) and 7 kVA (AC 230V).
Optional Accessories
EVO Handheld Remote Control
(Wired)
Order Code: HRC-04
EVO Handheld Remote Control
(Wireless)
Order Code: HRC-02
EVO Foot Pedal Control
(Wired)
Order Code: FRC-01
EVO Foot Pedal Control
(Wireless)
Order Code: FRC-02
EVO Inverter Trolley
Order Code: JIT-01
EVO Water Cooler
Order Code: LC-30
Smart
Lift-TIG
Dash-Arc
for HF TIG
Smart Gas
Wide Voltage
Adaptation
On Demand
Fan
Energy Saving
Environment
Friendly
Input
Power Source
Power Factor
Correction
PFC
DC Pulse TIG
Minimise the heat input without compromising on penetration. Alternating between a peak and base current reduces the amount of heat input and focuses the arc.
Intelligent Synergic Control
Getting set up for a weld has never been faster with our preset synergic programs. Simply select your wire type, wire size, gas type and material thickness, and the machine does the rest. It’ll pick the optimal settings for your weld.
Power Factor Correction (PFC)
Improves overall energy efficiency and allows use with AVR generators.
Smart Lift-TIG
The trigger controlled DC Lift Arc ignition allows the arc to be started easily by simply touching the tungsten to the workpiece and lifting it up to start the arc. This stops the tungsten tip sticking to the workpiece and breaking the tip from the tungsten electrode.
Advanced MMA Features
This machine features Anti-Stick technology, as well as adjustable Arc Force and Hot Start functionality. These features are designed for improving weld quality and ease of use.
Voltage Reduction Device
In MMA (Stick) mode VRD reduces the open-circuit voltage of the inverter.
When the welding machine is on, but not being used (like when you’ve just finished an electrode and need to grab a new one), the VRD kicks in and lowers the voltage to
a safer level (usually around 13V).
Active Balancing Air Passage
-
Internal airflow is optimally diverged by a segregation structure.
-
The divergence of airflow can dissipate heat generated by power electronics in a more balanced manner.
-
The power source's overall reliability is improved with the internal structure design.
Energy Saving Smart Fan
The on demand Smart Fan diminishes noise, saves power, helps reduce energy costs, and minimises the number of contaminants being pulled through the machine.
Quick Factory Reset
Quick reset to the factory programmed settings in the event of the operator selecting an incorrect setting.
Technical Data
